Product Details
+
Used, as new, still boxed.
- Professional performance amplifier with authentic Tube Logic tone
- Four analog Class AB power amp circuits, selectable from the panel: 6V6, 6L6, EL84, and EL34
- Streamlined combo design with 40 watts of power and custom 12-inch speaker
- Clean and lead channels, with standard and custom mode options
- Dynamically responsive power control for cranked-up sound and response at reduced volumes
- Nextone Editor (Mac/Windows) for customizing internal amp parameters, including tone stack type, EQ, sag, bias, effects, system settings, and much more
- Boost and Tone switches for adding crunch and sparkle
- Built-in delay, tremolo, and reverb effects, plus loop for patching in external effects
- External speaker jacks: one 8 ohm and two 16 ohm
- Line, USB, and phones/recording outputs, with three Air Feel mic’d cab settings selectable from the Nextone Editor
- Support for direct recording and re-amping via USB
Specifications:
- Rated Power Output: 40 W
- Speaker: 30 cm (12 inches) x 1
Nominal Input Level
- Input: -10 dBu (1 M ohm)
- Return In: -10 dBu (100 k ohm)
Controls
- Buttons: Ch Select button, Boost button, Tone button
- Clean Channel: Volume knob
- Lead Channel: Gain Knob, Volume knob
- EQ: Bass, Middle, Treble
- Effect: Delay button, Tap button, Delay knob, Reverb knob
- Other Controls: Presence knob, Master knob
- Power Amp Select switch: 6V6, 6L6, EL84, EL34
- Power Control Switch: STANDBY, 0.5 W, HALF, MAX
- Power Switch
- Indicators: CLEAN, LEAD, CUSTOM MODE, BOOST, TONE, DELAY,TAP
Connectors
- Input Jack: 1/4-inch phone type
- Rec Out/phones jack: Stereo 1/4-inch phone type
- Send jack: 1/4-inch phone type
- Return jack: 1/4-inch phone type
- Line Out jack: 1/4-inch phone type
- Speaker Out 16 ohms A jack: 1/4-inch phone type
- Speaker Out 16 ohms B jack: 1/4-inch phone type
- Speaker Out 8 ohms jack: 1/4-inch phone type
- Ch Select/boost jack: 1/4-inch TRS phone type
- Delay/ga-fc jack: 1/4-inch TRS phone type
- USB port: USB B type
- AC In jack
- Power Consumption: 37 W
Accessories
- Owner' s manual
- Power cord
- GA-FC sticker
Dimensions
- Width: 492mm
- Depth: 248mm
- Height: 427mm
- Weight: 13.4kg
