Additional Features:

• Frequency range: 20 Hz to 5 GHz
• RF attenuation switchable in wide range and small steps
• Refined preselection
• Very large frequency range for EMI measurements
• Low-noise preamplifier with wide dynamic range
• High-level mixer for IF conversion
• Additional filters ahead of IF preamplifier to avoid overloading due to broadband interference in IF section
• Highly linear envelope detector with dynamic range of 70 dB in addition to 110 dB logarithmic converter in analyzer path
• Five parallel detectors for peak, minimum, quasi-peak, average and RMS weighting
• DC logarithmic converter with dynamic range of 70 dB
• Overload detectors at the mixers and in the test channel toa void incorrect measurements

The EMI Test Receiver ESBI combines the top-class specifications of Rohde&Schwarz EMI test receivers with the speed of Rohde&Schwarz spectrum analyzers. The integral measurement and analysis functions simplify and speed up all measurements to the relevant commercial and military standards such as CISPR, VDE, FCC, EN, VCCI, MIL-STD, VG, DEF-STAN, BS, DO 160, GAM-EG13.
