Item# 1193

Features:

• One 30A AC ELCI Main Residual Current Circuit Breaker, leakage trip amperate - 30 mA
• ELCI provides overcurrent and leakage protection per ABYC E-11 for whole boat shore power protection
• Four 15A AC Branch Flat Rocker Circuit Breakers
• Red " Reverse Polarity" LED
• Includes 4206 AC Panel Basic Square Format Label Set
• All circuit label positions are backlit
• "ON" indicating LEDs

Specifications:

• Positions:5
• Nominal Voltage:120V AC
• Height:4.75in (120.65 mm)
• Width:9.25in (234.95 mm)
• Depth:3.99in (101.35 mm)
• Weight:1.00lb (0.45 kg)
